Ordering number : ENA1444A
SFT1341
P-Channel Power MOSFET
–40V, –10A, 112m Ω , Single TP/TP-FA
Features
http://onsemi.com
?
1.8V drive
?
Protection diode in
Speci ? cations
Absolute Maximum Ratings at Ta=25°C
Parameter
Drain-to-Source Voltage
Gate-to-Source Voltage
Drain Current (DC)
Symbol
VDSS
VGSS
ID
Conditions
Ratings
--40
±10
--10
Unit
V
V
A
Drain Current (PW ≤ 10 μ s)
Allowable Power Dissipation
Channel Temperature
Storage Temperature
IDP
PD
Tch
Tstg
PW ≤ 10 μ s, duty cycle ≤ 1%
Tc=25 ° C
--40
1.0
15
150
--55 to +150
A
W
W
°C
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating
Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
Package Dimensions unit : mm (typ)
7518-004
Package Dimensions unit : mm (typ)
7003-004
6.5
5.0
2.3
0.5
SFT1341-E
6.5
5.0
2.3
0.5
SFT1341-TL-E
4
4
0.85
0.7
1.2
0.85
1
2
3
0.5
0.6
1
2
3
0.5
1 : Gate
2 : Drain
3 : Source
4 : Drain
0.6
2.3
2.3
0 to 0.2
1.2
1 : Gate
2 : Drain
3 : Source
4 : Drain
2.3
2.3
TP
TP-FA
Product & Package Information
? Package : TP
? JEITA, JEDEC : SC-64, TO-251
? Package : TP-FA
? JEITA, JEDEC : SC-63, TO-252
? Minimum Packing Quantity : 500 pcs./bag
Marking
(TP, TP-FA)
T1341
LOT No.
? Minimum Packing Quantity : 700 pcs./reel
Packing Type (TP-FA) : TL Electrical Connection
1
2, 4
TL
3
Semiconductor Components Industries, LLC, 2013
July, 2013
60612 TKIM/40809PA MSIM TC-00001932 No. A1444-1/9
